MacDon FlexDraper FD140 - Page 51

214683 27 Revision A
Figure 2.4: Combine Side of FM100 Float Module
1016972
A
B
C
D
E
F
G
H
H
J
G
A - Float Module Gearbox B - Hydraulic Compartment Cover C - Reservoir Oil Level Sight Glass
D - Center-Link E - Header Height Control Indicator F - Torque Wrench
G - Drain Tube (x2) H - Float Lock Handle (x2) J - Auto Header Height Control (AHHC) Sensor
PRODUCT OVERVIEW
