214683 370 Revision A
Figure 4.137: Float Module Receptacles
12. Replace the cover (A) on the float module receptacle.
Figure 4.138: Feeder House Locks
13. Lift the lever (A) and pull and lower the handle (B) to
disengage the feeder house/float module lock (C).
Figure 4.139: Header on Combine
14. Lower the feeder house (A) until the feeder house
disengages the float module support (B).
15. Back the combine slowly away from the header.
HEADER ATTACHMENT/DETACHMENT
