214683 347 Revision A
Figure 4.83: Challenger and Massey Ferguson
Figure 4.84: Gleaner R and S Series
10. Use the lock handle (B) to retract the lugs (A) at the
base of the feeder house.
Figure 4.85: Float Module on Combine
11. Lower the feeder house until the saddle (A) disengages
and clears the float module support (B).
12. Back the combine away slowly from the float module.
HEADER ATTACHMENT/DETACHMENT
