Figure 5.304: Electrical Harness
9. Connect the electrical harness (A).
IMPORTANT:
Ensure the sensor electrical harness does NOT contact
the chain or sprocket.
10. Reinstall the drive cover. Refer to Installing Reel Drive
Cover, page 527.
11. Verify proper operation of the sensor.
