Manitowoc GROVE GMK3060

Crane operation
11.4 Operation of the rated capacity limiter
11 - 40 3 302 819 en Operating manual
GMK3060
13.12.2018
Outrigger span
You can adopt the outrigger span provided by the outrigger span monitoring or
manually enter the outrigger span.
Adopt the outrigger span
• Select and confirm the symbol (2).
The outrigger span provided by the outrigger
span monitoring is adopted and shown on the
current display (1).
At the same time, the current telescoping is
adopted and shown on the display (3).
• Always check that the currently rigged outrigger
span is displayed before confirming the rigging
mode.
Enter outrigger span (Standard)
• Select and confirm the display (1).
• Select the rigged outrigger span, e.g.
symbol (2) for 6.825 x 4.400 m (22.4 x 14.4 ft).
• Confirm the selection.
The selection and the corresponding RCL
code (3) are displayed.
If the outrigger span provided by the outrigger
span monitoring deviates from the entered value
then a query is displayed after confirming the
rigging mode;
à p. 11 - 46.
