31 Appendix
917 Coulometer
￭￭￭￭￭￭￭￭
299
Assignment Pin No. Function
Output 13 20
0 volts / GND 14
+5 volts 15
0 volts / GND 25
Table 13 Explanation of the individual functions
Function Explanation
Start The current method is started at the time of acti-
vation.
t
pulse
> 100 ms
Stop The current method is canceled (Stop) at the time
of activation.
t
pulse
> 100 ms
Quit The current command in the determination run
will be canceled at the time of activation.
t
pulse
> 100 ms
Ready The instrument is ready to receive a start signal.
Conditioning OK
Determination The instrument performs a data-generating
determination.
EOD End of Determination.
Error The line is set for error message display.
Warning The line is set for warning message display.
