Introduction Configuring the TM80
12 - 2 TM80 Telemetry Monitor Operator’s Manual
12.1 Introduction
The Maintenance menu provides access to the system settings such as location, device
name, alarm settings, quick keys, screen lock, and password updates. Entering this menu
requires a passcode.
12.2 Entering the Maintenance menu
1. In the main menu, tap Maintenance.
2. Input the maintenance passcode.
3. Tap Accept to enter the Maintenance menu.
12.3 Configuring the General Menu
1. In the Maintenance menu, tap General.
The current setting displays to the right of the option.
2. Select the options described in the following table.
Options Description Settings*
Display Auto Off Configures the time for display auto off. 1 min, 2 min, 5 min, 15 min 30
min, Off
Language Configures the system language. ENGLISH, FRENCH
Device Location Changes the hospital ,department name,
room number, and bed number.
Refer to "Configuring Device Location"
on page 12 - 3 for details.
N/A
Notch Filter Configures the ECG Notch filter. This
option is used to filter out AC line noise
from the ECG waveform.
50 Hz, 60 Hz, Off
The default is 50 Hz when the
monitor is not configured for the
US.
ECG Lead Labeling Changes the ECG lead labeling. AHA, IEC
Calibrate ECG Enables or disables the ECG verification. On, Off
Refer to "Verifying the ECG" on
page 17 - 5 for details.
SpO
2
Module Changes the SpO
2
module. Masimo SpO
2
, Nellcor SpO
2
SpO
2
Tone Configures the SpO
2
tone. Mode 1, Mode 2
* The factory default settings are in bold.
