General Product Description Touch Screen Display
TM80 Telemetry Monitor Operator’s Manual 2 - 7
◆ indicates that the TM80 has been connected to the Wi-Fi access point
and the signal coverage is good. Stable data transmission via Wi-Fi network
can be guaranteed.
◆ indicates that the TM80 has been connected to the Wi-Fi access point
and the signal coverage can basically meet the requirements. Stable data
transmission via Wi-Fi network can be guaranteed.
◆ indicates that the TM80 has been connected to the Wi-Fi access point
and the signal coverage is weak. Wi-Fi offline may occur.
◆ indicates that the TM80 is not connected to the Wi-Fi access point.
5. Battery symbol
This symbol indicates the battery charge status. For details about the battery sta-
tus symbols, refer to "Checking the Battery Charge Status" on page 14 - 4. Tap-
ping the battery symbol opens the System Info menu and displays the battery
information.
6. System time
7. Prompt message area
This area shows physiological alarm messages, technical alarm messages, and
informational messages. When there are multiple messages, the messages scroll.
Tapping this area displays the Alarm List menu where you can view all the alarm
messages. The “...” symbol indicates that there are more than one message.
8. Patient data area
This user configurable area can display parameter/waveform data. The parameter/
waveform is labeled in the upper left corner. You may also tap this area to display
the setup menu for the corresponding parameter/waveform.
For details about the touch screen operations, refer to "Basic Operations" on page 3 - 9.
