4 - 20 (00292)H
AE Select automatic exposure function. Set with the fx-K5 and GX,HX cameras.
Refer to page 4-45 for details.
OFF No automatic exposure.
LOW Low average image brightness.
NORMAL Normal average image brightness.
HIGH High average image brightness.
AE CYCLE Designate the automatic exposure cycle. Set with fx-K5 cameras.
Gain Brightness
LOW, NORMAL, HIGH can be set with the MEMRECAM HX, GX, Q camera.
LOW Lower gain by one aperture.
NORMAL Normal brightness.
HIGH Raise gain by one aperture.
Set from 0dB, +6dB, +12dB with the MEMRECAM fx series.
0db Normal brightness.
+6db Raise gain by one aperture.
+12 db Raise gain by two apertures.
Gamma Gamma correction
OFF No gamma correction.
LOW Low gamma correction.
NORMAL Normal gamma correction.
White Balance White Balance
AUTO Auto white balance setting.
3100K Setting for 3100K color temperature.
5000K Setting for 5000K color temperature.
9000K Setting for 9000K color temperature.
REG Uses the auto white balance setting obtained with SET during the preview.
SET Calculates the white balance data from the preview image.
With Q camera, white balance is automatically updated when changing white balance
settings or other camera settings. White balance is not updated when in VIEW or ARM
Enhance Enhance profile
OFF No enhance.
LOW Low enhance.
NORMAL Normal enhance.
HIGH High enhance.
Knee Turns correction expanding the dynamic range ON/OFF by lowering the
gain of the signals exceeding a specific brightness level.
ChromaColor depth (chroma)
0% Sets chroma to 0%. Black and white image.
50% Sets chroma to 50%.
100% Sets chroma to 100%. Standard chroma.
150% Sets chroma to 150%.
200% Sets chroma to 200%.
Comments Recording comments. Input setting up to 100 ASCII characters.
The three characters of [¥]["]['] as well as two byte Japanese characters
cannot be used. Characters can be copy and pasted, with the exception of
the restricted characters given above.
