Central Office Calls, Answering
76 ◆ Features DSX Software Manual
Setting Up Line and Loop Keys
1. For line keys:
- In 2121-[01 to 24]: Feature Key Codes (page 758), enter 03.
- In 2121-[01 to 24]: Feature Key Data (page 758), enter the line number (1-64).
- If an extension doesn’t have any line keys, you should assign Fixed or Switched Loop keys to
make handling outside calls easier.
2. For Fixed Loop keys:
- In 2121-[01 to 24]: Feature Key Codes (page 758), enter 01.
3. For Switched Loop keys:
- In 2121-[01 to 24]: Feature Key Codes (page 758), enter 02.
- In 2121-[01 to 24]: Feature Key Data (page 758), enter the Line Group number (90-98).
1. For line keys:
- In 2402-[01-60]: DSS Console Key Codes (page 801), enter 03.
- In 2402-[01-60]: DSS Console Key Data (page 801), enter the line number (1-64).
- Loop keys are not available on a DSS Console.
Setting Up Transmit and Receive Gain
1. If yes, leave 3103-01: Transmit Gain (page 814) for the line at it’s current value.
2. If no, in 3103-01: Transmit Gain (page 814) adjust the line’s transmit gain as required.
1. If yes, leave 3103-02: Receive Gain (page 814) for the line at it’s current value.
2. If no, in 3103-02: Receive Gain (page 814) adjust the line’s receive gain as required.
- For a “hot” (high gain) line, decreasing the receive gain should improve Handsfree performance for
keysets using that line.
1. Set up line and loop keys for an extension.
2. Set up line keys for a DSS Console.
1.
While on an outside call, is a user’s conversation transmitted to the caller at a comfortable
level?
2. While on an outside call, is the conversation received by the user at a comfortable level?
