NEC DSX Software Manual

Voice Mail
DSX Software Manual Features ◆ 375
Features
Programming
Basic Installation
1. Turn the system off.
2. Plug in the IntraMail CompactFlash card.
- In DSX-40, the card plugs directly into the equipment cabinet.
- In DSX-80/160, the card plugs into the CPU PCB.
3. Normally, you should leave the following at their default settings:
- 1312-01: Voice Mail Extension Number (page 624) (500-507).
- 4101-02: Voice Mail Master Number (page 864) (700).
- 4111-01: Voice Mail Port Name (page 865) (VM PORT #).
- 4112-02: Operator’s Extension (page 868) (300)
4. Turn the system on.
- The IntraMail will automatically install.
5. Add additional IntraMail mailboxes as required.
- In 2141-01: Station Mailbox Type (page 766), enter 1. This enables a Subscriber Mailbox for the
extension.
- By default in DSX-80/160, the first 16 mailboxes are enabled (extensions 300-315).
- By default in DSX-40, the first 8 mailboxes are enabled (extensions 300-307).
1. Plug the UltraMail PCB into any available slot (2-8).
- UltraMail will automatically install.
- Refer to the UltraMail/Aspire Mail System Guide for the specifics.
2. Normally, you should leave the following at their default settings:
- 1312-01: Voice Mail Extension Number (page 624) (500-507).
- 4101-02: Voice Mail Master Number (page 864) (700).
- 4111-01: Voice Mail Port Name (page 865) (VM PORT #).
- 4112-02: Operator’s Extension (page 868) (300)
1. For analog NVM-Series (such as NVM-2e):
- Plug each voice mail port into a corresponding analog port in the DSX system.
- In 1202-Ports (Primary Station Ports) (page 612), assign the analog ports used for voice mail sta-
tion numbers 201-208 as required.
2. For digital NVM-Series (such as Digital VANGARD):
- Plug each voice mail port into a corresponding digital port in the DSX System.
- In 1202-Ports (Primary Station Ports) (page 612), assign the digital ports used for voice mail sta-
tion numbers 201, 203, 205, and 207 as required.
- In 1203-Secondary Station Ports (page 613), assign the digital ports used for voice mail station
numbers 202, 204, 206, and 208 as required.
- When complete, the assignments for an 8-port Digital VANGARD would be as follows:
1. To install IntraMail:
2. To install UltraMail (DSX-80/160 only):
3. To install NVM-Series:
NVM-Series Station Port Assignments
Port 1 Port 2 Port 3 Port 4
Primary (1202)
201 203 205 207
