Voice Mail
374 ◆ Features DSX Software Manual
Call Forwarding Timers and Voice Mail
The following diagram shows how the system handles an outside call transferred to an extension that is for-
warded to voice mail.
Transferred Outside Call to Forwarded Extension
Conditions
• If an extension has a flashing Ring/Message lamp and the system resets or power fails, the lamp con-
tinues to flash after the system restarts.
• When using SLIU PCBs, the number of external voice mail ports you can install is limited by avail-
able system DTMF receivers.
• When the system rings an idle voice mail port, it will continue to ring the port until answered. The call
will not cycle to a another member of the UCD Group (as it will for voice calls).
• The system will never send a loop supervision disconnect signal (i.e., drop pulse) to voice mail ports.
Default Setting
• Voice mail is not installed.
1603-01: Transfer Recall Timer
(page 675)
1601-03: Call Forward No Answer
Timer (page 670)
The line rings extension B for the Transfer Recall
time. See Transfer (page 358) for more.
Extension A transfers line to extension B, which
is forwarded Busy/No Answer (type 2) to exten-
sion C.
If unanswered, the call then rings extension C
(the forward destination) for the Call Forward
Ring No Answer time.
If still unanswered, call diverts to Key Ring.
1601-03: Call Forward No Answer
Timer (page 670)
If still unanswered, the call rings the extension
that initially transferred the call (A) for the Call
Forward Ring No Answer time.
