Call Forwarding
46 ◆ Features DSX Software Manual
Call Forwarding Timers
The following diagrams show how the system implements various timers when handling forwarded calls.
Refer to the programming for each individual timer for more information.
Transferred Outside Call to Forwarded Extension
DIL (no overflow) to Forwarded Extension
1603-01: Transfer Recall Timer
(page 675)
1601-03: Call Forward No Answer
Timer (page 670)
The line rings extension B for the Transfer Recall
time. See Transfer (page 358) for more.
Extension A transfers line to extension B, which
is forwarded Busy/No Answer (type 2) to exten-
sion C.
If unanswered, the call then rings extension C
(the forward destination) for the Call Forward
Ring No Answer time.
If still unanswered, call diverts to Key Ring.
1601-03: Call Forward No Answer
Timer (page 670)
If still unanswered, the call rings the extension
that initially transferred the call (A) for the Call
Forward Ring No Answer time.
1601-02: DIL No Answer Timer
(page 669)
1601-02: DIL No Answer Timer
(page 669)
DIL rings programmed DIL destination for the
DIL No Answer time.
DIL (with no overflow) rings programmed desti-
nation, which is forwarded Busy/No Answer
(type 2) to a co-worker.
If unanswered, the call rings the extension to which
it is call forwarded for the DIL No Answer time.
If still unanswered, call diverts to Key Ring.
