Call Forwarding
DSX Software Manual Features ◆ 47
Features
DIL (with overflow) to Forwarded Extension
Outside Call on Hold at Forwarded Extension
Conditions
• An extension’s Call Forwarding is reinstated after a power down or system reset. For example, an
extension with calls forwarded immediately to voice mail will still be forwarded to voice mail after the
system resets or is powered down and then powered back up.
• The display CFWD Not Allowed indicates that an Call Forwarding is denied because it would set up
an illegal Call Forwarding loop. For example, if extension 305 if forwarded to 301, and 301 attempts
to forward to 305, the user at 305 would see the display
CFWD Not Allowed.
Default Setting
• Enabled
1601-02: DIL No Answer Timer
(page 669)
1601-02: DIL No Answer Timer
(page 669)
DIL rings programmed DIL destination for the
DIL No Answer time.
DIL (with overflow) rings programmed destina-
tion, which is forwarded Busy/No Answer (type
2) to a co-worker.
If unanswered, the call rings the extension to which
it is forwarded for the DIL No Answer time.
If still unanswered, call diverts to Key Ring.
1601-02: DIL No Answer Timer
(page 669)
If unanswered, the DIL rings the programmed
overflow destination for the DIL No Answer time.
1603-02: Hold Recall Timer
(page 675)
1601-01: Line No Answer Timer
(page 669)
If not picked up, outside call recalls the extension
that put it on Hold after the Hold Recall time.
Extension forwarded to co-worker using Busy/
No Answer (type 2) to a co-worker puts outside
call on Hold.
The call then rings the extension that put it on
Hold for the Line Revert time.
If still unanswered, call diverts to Key Ring.
