746 ◆ Station Options: 2101-2501 DSX Software Manual
UCD Hunting
Options
2115-01: Hunt Type
(Hunt Type)
Use this option to assign the hunt type for the extension.
Features
• Extension Hunting (page 154)
IntraMail Features
• Extension Hunting to Voice Mail (page 478)
Options
• 0 for none
• 1 for Ring No Answer Line
• 2 for Busy/Ring No Answer Line
• 3 for Busy/Ring No Answer All Calls
• 4 for Busy Line
• 5 for Uniform Call Distribution (UCD)
Default
• 0
2115-01: Hunt Destination
(Hunt Destination)
For type 1-4 hunting only, use this option to assign the next extension in the Circular or Terminal Hunt Group.
Features
• Extension Hunting (page 154)
IntraMail Features
• Extension Hunting to Voice Mail (page 478)
Options
• Extension number (0-999)
• None (entered by pressing CLEAR)
Default
• None
2115-01: UCD Group Master Number
(Hunt Master)
For type 5 hunting only, use this option to assign the hunt group
UCD Hunting Programming (for 301, 303 and 304 with master 701)
2115-01: Hunt Type Enter the Hunt Type 5 for all three extensions.
2115-01: UCD Group Master
Number
Enter 701 for all three extensions.
2302-01: UCD Group Overflow
Destination
Enter 305
1601-04: UCD No Answer Timer
This timer sets when UCD overflow occurs. When all UCD agents are
busy, a queued call rings for this interval and then overflows to the
destination set in 2302-01: UCD Group Overflow Destination .
