NEC DSX Software Manual

32xx-Groups
320x-Setup
3201-Order
DSX Software Manual Line Options: 3101-3714 ◆ 833
Line
3101-3715
32xx-Groups
320x-Setup3201-Order
Description
Use this program to set up Line Groups.
Options
3201-[01-64]: Line Group
(xx 1st line)
Use this option to program lines (1-64) into each of the nine Line Groups (90-98). The order in which you
enter lines into a group determines the order in which the system will access the lines when placing an out-
side call. A line can be in more than one group. In DSX-80/160, you can program a line into a group only if
the line is on an installed COIU PCB. If you program a line into a group, and then remove its PCB, the sys-
tem automatically removes the line from the group.
The following chart shows how you could set up Line Group 90 with lines 1-8 enter in descending order.
When placing an outgoing call using group 90, the system will try line 8 first and line 1 last.
Features
• Line Group Routing (page 223)
• Line Groups (page 225)
• Loop Keys (page 233)
• Speed Dial (page 315)
IntraMail Features
• None
Options
• Line 1-64 (for Line Group entries 1-64)
Default
• Lines 1-8 are in Line Group 90.
Sample Line Group Program Entry
Line Group Program entry number Line number
90 1
8
2
7
3
6
4
5
5
4
6
3
7
2
8
1
