DSX Software Manual System Options: 1001-1702 ◆ 611
System
1001-1702
12xx-Slots
120x-Stations1201-Type (Station Card Type)
Description
This program allows you to set the type for each station PCB plugged into your system.
Options
1201-01: Card Type
(Card Type)
Use this option to define the type of station PCB plugged into each equipment cabinet PCB slot. Although
PCBs auto-ID as you insert them, this option allows you to preconfigure a system prior to installation. You
can also use this option to reorder PCBs after the initial installation is complete.
F
eatures
• Automatic Slot Configuration (page 33)
IntraMail Features
• None
Options
• 1 for 16ESIU
• 2 for 16DSTU
• 3 for 4SLIU
• 4 for 8SLIU
• 5 for 16SLIU
• 6 for 2-port UltraMail
• 7 for 4-port UltraMail
• 8 for 6-port UltraMail
• 9 for 8-port UltraMail
Default
• N/A
