NEC DSX Software Manual

31xx-Configuration
312x-Caller ID
3121-Settings
DSX Software Manual Line Options: 3101-3714 ◆ 825
Line
3101-3715
312x-Caller ID3121-Settings
Description
Use this program to set the line Caller ID parameters.
If programming multiple lines, you may find 9022-Line Copy (page 923) a handy time-saving tool.
Options
3121-01: Caller ID Type
(CID Type)
Use this option to enable Caller ID for each line. If enabled, Caller ID will occur if also enabled by the other
Caller ID programmable options.
Features
• Caller ID (page 63)
• T1 Lines (page 338)
IntraMail Features
• Caller ID and Voice Mail (page 456)
• Make Call (page 525)
Options
• 0 for none
• 1 for DSP
• 2 for ATRU PCB daughter board
• 3 for T1/E1ANI
Default
•0
3121-02: ANI/DNIS Format
(ANI/DNIS Format)
Use this option to specify the type of ANI/DNIS Caller ID data provided by T1 lines. Set this option for com-
patibility with the incoming ANI/DNIS data provided by the local telco. When entering data, the options are:
Features
• Caller ID (page 63)
• T1 Lines (page 338)
IntraMail Features
• Caller ID and Voice Mail (page 456)
• Make Call (page 525)
ANI/DNIS Data Format
Option Description Entry
0
The DID line will not detect ANI/DNIS data.
NONE
1
The DID line will detect ANI data without using delimiters
ANI
2
The DID line will detect ANI data using a delimiter (*) at the begin-
ning and end of the ANI Caller ID string.
*ANI*
3
The DID line will detect DNIS data without using delimiters.
*DNIS*
4
The DID line will detect both ANI and DNIS data using a delimiter
(*) at the beginning and end of the string. An additional delimiter
separates the ANI and DNIS data.
*ANI*DNIS*
