Door Box
DSX Software Manual Features ◆ 149
Features
2PGDAD Module Door Box Setup
1. Locate an available 16ESIU PCB digital station port (e.g., station port 10/extension 309).
- If you wait to plug in the 2PGDAD Module until after your programming is complete, the second-
ary station port set up in the next step will auto-ID as a Door Box. The primary port always auto-
IDs as a Door Box when the 2PGDAD Module is plugged in.
2. In 1203-01: Secondary Station Port Assignment (page 613) for the station port you selected in step 1
above, enter an available station port for the secondary port.
- Station ports 96-127 are available by default.
- For example, enter port 110 (extension 409) as the secondary station port for station 10 (extension
309).
3. Following the instructions in your system’s Hardware Manual, connect the Door Boxes (P/N 922450) to
the 2PGDAD Module Door Box ports.
4. Plug the 2PGDAD Module into the 16ESIU digital station port you selected in step 1 above.
- If you plugged in the 2PGDAD in step 1 above, you’ll need to unplug and then reconnect it in order
for the secondary station port to auto-ID.
1. Refer to Basic Door Box Programming (page 148) for more.
1. The 2PGDAD relays are automatically assigned to their respective Door Box.
- 2PGDAD Door Box 1 is assigned to Relay 5.
- 2PGDAD Door Box 2 is assigned to Relay 6.
- Refer to the system’s Hardware Manual for more.
2. In 1605-03: Door Relay Unlock Timer (page 680), set the relay unlock (open) interval to meet the site
requirements.
1. If the 2PGDAD Door Box does not auto-ID, check the following programs for conflicts:
- In 1311-01: Station Extension Number (page 623) for the secondary channel, make sure there is an
extension number assigned.
- In 2101-01: Station Type (page 719), make sure the Door Box is circuit type 10.
1. Set up the 2PGDAD Module Door Box ports.
2. Set up the Door Box Ring Groups and chime sounds.
3. Set up the Door Box relays.
4. (Optional) Check for programming conflicts.
