Extension Hunting
DSX Software Manual Features ◆ 161
Features
Transfer to Hunt Group
Busy/Ring No Answer All Calls (Type 3) Circular and Terminal Hunting
Routing to Busy UCD Group with Overflow
1603-01: Transfer Recall Timer
(page 675)
1601-03: Call Forward No Answer
Timer (page 670)
Call rings extension A for the Transfer Recall
time.
Call transferred to extension A, which is the sin-
gle member of a type 3 hunt group that is set up
to hunt to extension B.
If unanswered at extension A, the call hunts to
extension B which is the single member to a type
5 UCD Group that is set up to overflow to exten-
sion C.
Extension B
The call now rings extension B for the Call
Forward No Answer time.
1601-03: Call Forward No Answer
Timer (page 670)
If a UCD Group member does not become free,
the call diverts to the programmed overflow desti-
nation.
If still unanswered, the call diverts to Key Ring.
Busy UCD
Master
If unanswered at extension B, the call
camps-on to the busy UCD master exten-
sion number.
1601-04: UCD No Answer Timer
(page 670)
The call camps-on to the UCD Group for the
UCD No Answer interval, waiting for a member
to become free. Note that the Call Coverage
Delay timer also starts now. See Call Coverage
Keys (page 40) for more.
UCD
Overflow
The call the rings the overflow destination
for the Call Forward No Answer time.
