Telephone Illustrations
10 ◆ Introduction DSX Software Manual
34-Button Display Telephone
ABC
JKL
TUV
VOLUME
GHI
PQRS
DEF
TRANSFER
FLASH
REDIAL
MUTE
SPEAKER
INTERCOM
CLEARCHECK
V-MAIL
DND
CONF
HOLD
MNO
WXYZ
1093100 - 1
In DSX-40:
Keys 1-8 are line keys.
Keys 9-24 are undefined.
In DSX-80/160:
Keys 1-12 are line keys.
Keys 13-24 are undefined.
For Attendants:
Key 24 is the
Operator Call key.
Speed Dial
Bin keys
Feature keys
Soft keys
Alpanumeric Display
Ring/Message Lamp
Microphone
Fixed Function keys
Thu June 8 11:52 AM
Pat Smith x301
Menu Dir VM:00 CL:00
Line 1 Line 2 Line 3 Line 4 Line 5 Line 6
Line 7 Line 8 Line 9 Line 10 Line 11 Line 12
