Cam Nodes
The initial values of the cam node variable are given in the following table.
Ele-
me
nt
No.
Phase
(Master
Axis
Phase)
Distance
(Slave
Axis Dis-
place-
ment)
Curve
(Curve Shape)
Connecting-
V
elEnable
(Connecting
Velocity Ena-
ble)
Connec-
tingVel
(Connect-
ing Veloc-
ity)
Connec-
tingAc-
cEnable
(Connect-
ing Accel-
eration
Enable)
Connectin-
gAcc
(Connecting
Acceleration)
Phase-
Pitch
(Phase
Pitch)
0 180.000 -100.000 _mcModifiedSine FALSE 0.000 FALSE 0.000 0.010
1 360.000 0.000 _mcPolynomic5 FALSE 0.000 FALSE 0.000 0.010
2 0.0 0.0 _mcConstantLine FALSE 0.000 FALSE 0.0 0.0
3 0.0 0.0 _mcConstantLine FALSE 0.000 FALSE 0.0 0.0
The sample programming changes the curve shape for element 0 and adds a node point to element 1.
Ele-
me
nt
No.
Phase
(Master
Axis
Phase)
Distance
(Slave
Axis Dis-
place-
ment)
Curve
(Curve Shape)
Connecting-
V
elEnable
(Connecting
Velocity Ena-
ble)
Connec-
tingVel
(Connect-
ing Veloc-
ity)
Connec-
tingAc-
cEnable
(Connect-
ing Accel-
eration
Enable)
Connectin-
gAcc
(Connecting
Acceleration)
Phase-
Pitch
(Phase
Pitch)
0 180.000 -100.000 _mcPolynomic5 FALSE 0.000 FALSE 0.000 0.010
1 200.000 -102.000 _mcStraight-
Line
FALSE 0.000 FALSE 0.000 0.010
2 360.000 0.000 _mcPolynomic5 FALSE 0.000 FALSE 0.000 0.010
3 0.0 0.0 _mcConstantLine FALSE 0.000 FALSE 0.0 0.0
Ladder Diagram
Main Variables
Name Data type Default Comment
MC_Axis000 _sAXIS_REF --- Axis Variable for the master axis,
axis 1.
MC_Axis001 _sAXIS_REF --- Axis Variable for the slave axis,
axis 2.
CamProfile0 ARRAY[0..36000] OF
_sMC_CAM_REF
--- This is the cam data variable.
The cam data variable is created
in advance on the Cam Editor of
the Sysmac Studio.
Pwr1_Status BOOL --- This variable is assigned to the
Status output variable from the
PWR1 instance of the MC_Power
instruction. This variable changes
to TRUE when the Servo is
turned ON.
5 Common Command Instructions
5-35
NY-series Motion Control Instructions Reference Manual (W561)
MC_GenerateCamTable
5
Sample Programming
To Next Page
