Parameter Reference C-97
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Inverts all the digital inputs to the drive as a 16-bit word. The bits within the word may be accessed individually, or the entire word may
be accessed as a group.
Bit
Signal name
Terminal
Comment
PNO for individual bit access
0
Inv Digin 01
X13.2
1295
1
Inv Digin 02
X13.3
1296
2
Inv Digin 03
X13.4
1297
3
Inv Digin 04
X12.1
Common terminal with digital output 1
1298
4
Inv Digin 05
X12.2
Common terminal with digital output 2
1299
5
Inv Digin 06
X12.3
Common terminal with digital output 3
1300
6
Inv Digin 07
X12.4
Common terminal with digital output 4
1301
7
Inv STO Inactive
X10
1302
8
Inv Digin 11
X20.1
GPIO option
1303
9
Inv Digin 12
X20.2
GPIO option
1304
10
Inv Digin 13
X20.3
GPIO option
1305
11
Inv Digin 14
X20.4
GPIO option
1306
12
Inv Run Key
-
GKP Run key pressed*
1307
13
Inv Not Stop Key
-
GKP Stop key not pressed*
1308
14
Inv Stop Key
-
GKP Stop key pressed*
1309
