Parker AC30 series User Manual

C-180 Parameter Reference
AC30 series Variable Speed Drive
SB Encoder Slot 1
Parameters::System Board::Encoder Slot 1
This feature allows you to setup and monitor the operation of the encoder attached to slot 1 of the system board.
Parameter Name
No.
Path
Default
Range
Units
Writable
Encoder Supply
1663 Setup::Inputs and Outputs::SB Encoder
Slot1
Parameters::System Board::SB Encoder
Slot 1
0 0:5 V
1:12 V
2:15 V
3:20 V
STOPPED
Configures the encoder supply for both Encoder 1 and Encoder 2
Encoder Lines
1664 Same as PNO 1663 2048 1 to 100000 STOPPED
The number of lines per encoder revolution
Encoder Invert
1665 Same as PNO 1663 FALSE STOPPED
Reverses the encoder direction if TRUE.
Encoder Type
1666 Same as PNO 1663 0
0:QUADRATURE
1:CLOCK/DIRECTION
Normally the encoder will be quadrature. Exceptionally, eg if a proximity sensor or other pulse train is used, it needs to be clock /
direction.
High Input Threshold
1667 Same as PNO 1663 FALSE STOPPED
Changes the threshold level for the encoder pulses between 1.8 V and 6.5 V typical. For encoders powered from 5 V the low theshold
should be used. For other supply voltages the high threshold will provide greater noise immunity.
Encoder Speed
1668 Monitor::System Board::SB Encoder Slot
1
Parameters::System Board::SB Encoder
Slot 1
RPM NEVER
The speed measured by the encoder, in revolutions per minute.
