Chapter 5 Maintaining Your Library
Maintenance Actions
Scalar i2000 User’s Guide 302
Verification Test Logs 5
Each verification test produces a test log that details all information and
results from the individual tests and subtests. In addition, the log includes
information to help you understand the test results and to help resolve any
problems encountered. To view a test log, click Reports on the
Verification Tests dialog box to display the report window, and then click
the Text tab.
You can view results for the five most recent tests. Click Reports, and then
click the test results you want to view.
This log file is appended with data as each test finishes. You can repeat the
test if any problems are found and fixed. If the Verification Tests dialog
box was not closed during the retesting, all results are contained in one log
file.
To save the information that the test generates, click Send. If you are using
the remote LMC client, you can choose to save the log to your hard drive.
If you choose to save directly to your hard drive, the report listing and test
log are combined into one text file.
Figure 30 on page 303 shows an example of a test log. It provides the
following information:
• The test output is from the library alignment test.
• The test title is always shown between rows of equal signs.
• A brief guide for understanding coordinates and offsets used in the
test results is provided near the beginning of the log.
• The X-axis and Y-axis limits applied by this test are shown.
MARGINAL output is placed between parentheses, and FAILED
output is placed between brackets; for example, (30) and [45].
• The results of the subtest are displayed between dashed lines.
• Coordinates are represented as A (aisle), F (frame), R (rack), S
(section), C (column), and R (row).
• All location values are in 0.1 mm.
• All results that you should review are identified with four arrows
(>>>>) in the column to the left of the detailed results.
• At the end of every test, summary results of every subtest are given.
The overall test result is displayed between asterisk lines, and a
summary of subtest results follows. See
figure 30 on page 303.
