Chapter 6 Running Your Library
Library Management Console (LMC)
Scalar i2000 User’s Guide 365
Each button displays a status indicator that reveals a Good, Warning,
Degraded, or Failed state as follows:
For example, the buttons shown in figure 36 indicate that all subsystems
are functioning normally (Good), while those shown in figure 37 indicate
that issues exist in the Drives and Robotics subsystems.
Figure 37 Status Buttons -
Drives and Robotics Issues
You can click system status buttons to display additional information
about the subsystems. The information that appears depends on the status
shown on the button:
Cooling Cooling system components, such as fans for the library management module
(LMM) and the I/O management unit
Good (green)
Warning or Degraded
(yellow)
Failed (flashing red)
Table 30 Subsystems and
Their Components (Continued)
Subsystem Components
indicates Failed status
indicates Warning or Degraded status
