Chapter 4 Configuring Your Library
Configuring Devices
Scalar i2000 User’s Guide 164
The following table describes the descriptors that appear in the Show
Details view for drives.
Table 23 Descriptors
In the default view, only the names of available partitions and the names
of the devices (drives) are shown. LUN spaces from 0-255 are available. In
the Show Details view, a partition that has not yet been manually
reassigned to a new map position appears in heavy black type in the
Internal LUN column. Partitions are treated by the system as devices. You
must assign a partition to the LUN/External LUN column for the LMC to
manage it and its media. In this example, the control LUN has already
been remapped as shown in heavy black type in the LUN/External LUN
column.
2 If you are working from the local touch screen, you must select an
internal device LUN, select the left arrow, and then select the desired
external LUN. If you are working from the remote client, you can use
the select method or you can drag and drop the devices from the
Internal LUN column to the appropriate LUN assignment in the
LUN/External LUN column. Always use LUN 0 for command and
control.
Descriptor Description
[Number]
[Connection Type]
[Port Connection]
[LUN] [Fibre or SCSI] [Port Number].
Vendor ID Drive manufacturer.
Serial Number Drive serial number.
Partition Name of the partition with which the drive is associated.
