Quantum Scalar i2000 User Manual

Chapter 3 Description
Support for WORM
Scalar i2000 User’s Guide 93
There are two types of magazines: one for DLT and another for LTO.
Because the two magazines are the same size, they can be mixed in the
library. DLT magazines hold five cartridges, and LTO magazines hold six
cartridges.
Each magazine has a barcode label that the scanner reads for
identification and inventory. An optional, snap-on dust cover is available
for the magazines. Magazines with the dust cover have interlocked
stacking that enables easier storage of the media when they are removed
from the library for external storage.
Support for WORM
The Scalar i2000 library supports WORM (write once, read many)
technology in LTO-3 and LTO-4 tape drives. WORM requirements
include:
Table 15 Cartridge Capacities
in Library Modules
Type of
Cartridge
Cartridges
per
Magazine
Magazines
per Control
Module
a
a.The minimum is based on having 11 additional drives installed. The maximum is based on having one drive
and one I/E station installed.
Magazines per
Expansion
Module
b
b.The minimum is based on having an I/E station and 12 drives installed. The maximum is based on having
no drives or an I/E station installed.
Control Module
Cartridge
Capacity
c
c.The minimum is based on having 11 additional drives installed. The maximum is based on having one drive
and one I/E station installed.
Expansion
Module Cartridge
Capacity
d
d. The minimum is based on having an I/E station and 12 drives installed. The maximum is based on having
no drives or an I/E station installed.
DLT 5 44 min/51
max
50 min/76 max 220 min/255 max 250 min/380 max
LTO 6 44 min/51
max
50 min/76 max 264 min/306 max 300 min/456 max
