Chapter 3 Description
Scalar i2000 User’s Guide 78
Figure 11 Front View of a
Control Module and Expansion
Module
The library is designed for ease of installation, configuration, and field
upgrades. The minimum library configuration consists of one control
module. You can add up to seven expansion modules as storage and tape
drive requirements change. The maximum library configuration can
accommodate from 102 to 3,492 LTO cartridges or from 100 to 2,915 DLT
cartridges, from 1 to 96 tape drives, and from 1 to 8 Import/Export (I/E)
stations.
control module
expansion module
touch screen
I/E station
access doors
operator panel
