Chapter 2 Troubleshooting Your Library
Interpreting LEDs
Scalar i2000 User’s Guide 57
Figure 4 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-3 drive sled.
Figure 4 Rear View of Fibre
Channel Drive Sled (UDS-3)
Table 6 on page 58 describes how to interpret the drive sled status LED
activity that you might see on the rear of a UDS-2 or UDS-3 drive sled.
For a description of how the blade status LEDs appear under normal
conditions, see
table 7 on page 59. For information about interpreting the
drive link LED, see Drive Sled Fibre Channel Link LED on page 59.
- top = blue
- middle = amber
- bottom = green
status LEDs:
LED for future use
fibre port
FC Link
LED
