Chapter 6 Running Your Library
Understanding Location Coordinates
Scalar i2000 User’s Guide 374
• Drive number 1 is in the lowest section of the lower drive cluster.
Drives are numbered from bottom to top.
Figure 44 on page 375
shows the physical location of drive 9, which is the last drive listed in
the Move Media dialog box shown in
figure 43. Compare with
table 31.
Figure 43 Location
Coordinates for Drives
Table 31 Drive Location
Coordinates
1 1-8 1 1-12 1 1
Aisle Module Rack Section Column Row
