Chapter 3 Description
Expansion Modules
Scalar i2000 User’s Guide 84
Figure 12 Front and Back View
of the Control Module
Expansion Modules
Expansion modules enable the library to expand by adding space for tape
drives, I/E stations, and cartridges. Each expansion module adds 300 to
456 LTO or 250 to 380 DLT cartridge slots, depending on the number of
tape drives installed and whether an I/E station is installed (see
figure 13
on page 85). The library’s maximum configuration includes up to seven
power
supplies
library
management
magazines
module
drive
picker
I/E
station
accessor
and
cartridge
slots
front view back view
clusters
I/O
management
unit
