Chapter 2 Troubleshooting Your Library
Interpreting LEDs
Scalar i2000 User’s Guide 65
Table 11 describes how to interpret the Ethernet port LED activity that
you might see.
Table 11 Explanations of MCB
Ethernet Port LED States
MCB Fibre Channel and SCSI Port LEDs 2
The LEDs for the MCB Fibre Channel and SCSI ports are for future use.
Ignore LED behaviors that might appear.
Figure 7 on page 66 shows the
locations and colors of the LEDs.
LED Color Possible States and Explanations
Green • Solid on — the link is up; data can be sent or received through the Ethernet port
• Solid off — the link is not up; data cannot be sent or received through the Ethernet
port
Amber • Flashes at irregular intervals — data activity is occurring through the Ethernet port
• Solid off — no data activity is occurring through the Ethernet port
