Chapter 3 Description
Cartridge Magazines
Scalar i2000 User’s Guide 92
Cartridge Magazines
The cartridge magazine is a storage assembly that installs on the drive
side or door side of the control module or expansion module, as shown in
figure 17. It contains the cartridge slots and provides flexibility when
adding storage cartridges to a module.
Figure 17 Magazine and Drive
Locations in the Control Module
I/E
cartridge
magazines
station
door sidedrive side
drives or
storage
upper
drive
cluster
lower
drive
cluster
