Chapter 2 Troubleshooting Your Library
Interpreting LEDs
Scalar i2000 User’s Guide 64
Interpreting MCB Port
LEDs 2
The MCB has LEDs for the Ethernet, Fibre Channel, and SCSI ports.
MCB Ethernet Port LEDs 2
The LEDs on the MCB Ethernet port indicate status and activity. Figure 6
shows the locations and colors of the MCB Ethernet port LEDs.
Figure 6 Locations - Colors of
MCB Ethernet Port LEDs
MCB Ethernet
port LEDs
- top = green
- bottom = amber
To Next Page
