Chapter 6 Running Your Library
Understanding Location Coordinates
Scalar i2000 User’s Guide 366
• Good — either a message appears informing you that no tickets exist
for the subsystem or a list of subsystem tickets appears that are in
Closed or Verified states
• Warning, Degraded, or Failed — a list of open tickets for the
subsystem appears
Tickets provide information about issues that the library has detected. For
more information, see
Using System Status Buttons to Display Ticket Lists
on page 16.
Understanding Location Coordinates
This section describes the coordinate addressing system that the library
uses to indicate the location of cartridges, drives, and I/O blades in the
library.
You can use the Library Explorer feature to view a graphical presentation
of all the drives, cartridges, and slots in the library. The Library Explorer
can display all library elements according to physical location in any
configuration, from one module to eight modules, and one drive up to the
maximum number of 96 drives. For more information on Library
Explorer, see
Using Library Explorer on page 234.
Cartridge Locations 6
The library uses a coordinate addressing system that indicates the
location of cartridges using six coordinates. The coordinates are
represented by the library in a comma separated list. For example:
1,1,1,1,2,1 = aisle 1, module 1, rack 1, section 1, column 2, row 1
