Chapter 2 Troubleshooting Your Library
Interpreting LEDs
Scalar i2000 User’s Guide 66
Figure 7 Locations - Colors
MCB FC / SCSI Port LEDs
Interpreting LBX
Terminator LEDs 2
The LBX terminator has two versions. Version 01 has four LEDs and
Version 03 has six LEDs. For more information, see the Scalar i2000
Maintenance Guide.
LBX Terminator Version 01 LEDs 2
The LBX terminator has four green LEDs that indicate the presence of
modules in the library.
Figure 8 on page 67 shows the locations of the
LEDs. Table 12 on page 67 describes how to interpret LED activity on the
LBX terminator.
MCB port LEDs
- left = green (belongs to
SCSI port below)
- right = green (belongs
to FC port above)
