Chapter 4 Configuring Your Library
Managing Connectivity
Scalar i2000 User’s Guide 129
Managing Connectivity
The Connectivity command on the Setup menu enables you to access
three connectivity-related commands for the library: Port Configuration,
Datapath Conditioning, and FC Host Port Failover.
For information about configuring data path conditioning monitoring
levels and intervals, see
Configuring Datapath Conditioning on page 198.
Port Configuration 4
Use the Port Configuration command to view and configure connectivity
parameters for FC ports. Port Configuration gives you access to the FC
ports on the MCB and on the I/O blades.
1 Log on as an administrator.
2 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
3 Click Setup→ Connectivity→ Port Configuration.
The Connectivity dialog box appears. All components that provide FC
and SCSI ports appear in the dialog box if they are detected. You cannot
configure settings for the SCSI port on the MCB.
4 This example shows expanded levels for “MCB” and “IO Blade -
1,1,1,1,3”. Click the highest-level items to show next-level items.
5 Click a port to highlight it, and then click Configure.
