Command reference
R&S
®
ZNL/ZNLE
738User Manual 1178.5966.02 ─ 20
Usage: Query only
Options: R&S ZNL-K3
Manual operation: See "Fault Table" on page 375
CALCulate<Chn>:TRANsform:DTFault:PEAK:DATA<FaultNo>
If the active trace of channel <Chn> is a Distance to Fault (DtF) trace and DtF limit
checking is enabled, this query returns the peak data of DtF limit violation <FaultNo>
<FaultNo> must be between 1 and CALCulate<Chn>:TRANsform:DTFault:PEAK:
COUNt?. The peak data are returned as value pair distance, response value.
Peaks are numbered according to their distance (fault no. 1 has the smallest distance).
Use CALCulate<Chn>:TRANsform:DTFault:PEAK:STATe to enable DtF limit
checking and CALCulate<Chn>:TRANsform:DTFault:PEAK:THReshold to set
the fault limit.
Suffix:
<Chn>
.
Channel number used to identify the active trace
<FaultNo> 1 ... CALCulate<Chn>:TRANsform:DTFault:PEAK:COUNt?
Example: Suppose CALCulate1:TRANsform:DTFault:PEAK:COUNt?
returns 3, then
CALCulate1:TRANsform:DTFault:PEAK:DATA1; DATA2;
DATA3
returns the coordinates of the DtF limit violation peaks.
Options: R&S ZNL-K3
Manual operation: See "Fault Table" on page 375
CALCulate<Chn>:TRANsform:DTFault:PEAK:STATe <DtfPeakState>
If the active trace of channel <Chn> is a Distance to Fault (DtF) trace, this command
allows to enable/disable DtF limit checking.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<DtfPeakState> OFF|ON (0|1)
Example:
*RST; :CALCulate1:TRANsform:DTFault:STATe ON
makes the active trace of channel 1 a DtF trace.
CALCulate1:TRANsform:DTFault:PEAK:STATe ON
enables DtF limit checking.
Options: R&S ZNL-K3
Manual operation: See "Fault Limit Check" on page 371
