R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
775User Manual 1178.5966.02 ─ 20
Parameters for setting and query:
<CircuitModel> SL | SC
Possible circuit models (character data); see Table 11-12.
Example:
*RST; :CALC:TRAN:VNET:GLO:EMB:PAR:R? SC; R? SL
Query the default resistances for ground loop embedding. The
response is 10000000; 0.
CALC:TRAN:VNET:GLO:EMB:PAR:R SC, 2.2E+3
Increase the resistance for the Shunt C model to 2.2 kΩ.
Manual operation: See "Network" on page 558
CALCulate<Ch>:TRANsform:VNETworks:GLOop:EMBedding[:STATe]
<Boolean>
Enables or disables the embedding function for ground loops. It is allowed to change
the circuit model and its parameters while embedding is enabled.
Suffix:
<Ch>
.
Channel number.
Parameters:
<Boolean> ON - Embedding active
OFF - Embedding inactive
*RST: OFF
Example:
CALC:TRAN:VNET:GLO:EMB:TND SL
Select the Shunt L circuit model for embedding.
CALC:TRAN:VNET:GLO:EMB:PAR:R SL, 2.2E+3; :CALC:
TRAN:VNET:GLO:EMB ON
Increase the resistance for the Shunt L circuit model to 2.2 kΩ
and enable embedding.
Manual operation: See "Active" on page 540
CALCulate<Ch>:TRANsform:VNETworks:GLOop:EMBedding:TNDefinition
<CircuitModel>
Selects the circuit model for ground loop embedding.
Suffix:
<Ch>
.
Channel number.
Parameters:
<CircuitModel> FIMPort | SL | SC | SG
Possible circuit models (character data); see Circuit models for
ground loop de-/embedding.
*RST: FIMPort
Example: See CALCulate<Ch>:TRANsform:VNETworks:GLOop:
EMBedding[:STATe] on page 775
Manual operation: See "Network" on page 558
VNA command reference
