R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
790User Manual 1178.5966.02 ─ 20
CALCulate<Ch>:TRANsform:VNETworks:SENDed:DEEMbedding<PhyPt>[:
STATe] <Boolean>
Enables or disables the deembedding function for single ended ports. It is allowed to
change the circuit model and its parameters while deembedding is enabled.
Suffix:
<Ch>
.
Channel number
<PhyPt> Physical port number
Parameters:
<Boolean> ON - deembedding active
OFF - deembedding inactive
*RST: OFF
Example:
CALC:TRAN:VNET:SEND:DEEM:TND CSL
Select the Serial C, shunt L circuit model for deembedding.
CALC:TRAN:VNET:SEND:DEEM:PAR:R2 CSL, 2.2E+3; :
CALC:TRAN:VNET:SEND:DEEM ON
Increase the resistance R2 for the Serial C, shunt L circuit model
to 2.2 kΩ and enable deembedding.
Manual operation: See "Active" on page 536
CALCulate<Ch>:TRANsform:VNETworks:SENDed:DEEMbedding<PhyPt>:
TNDefinition <CircuitModel>
Selects the circuit model for single ended port deembedding.
Suffix:
<Ch>
.
Channel number
<PhyPt> Physical port number
Parameters:
<CircuitModel> FIMPort | CSL | LSC | CSC | LSL | SLC | SCL | SCC | SLL |
SHLC | GSL | LSG | GSG | SLG | SGL | SGG
Possible circuit models (character data); see Table 11-9
*RST: CSL
Example: See CALCulate<Ch>:TRANsform:VNETworks:SENDed:
DEEMbedding<PhyPt>[:STATe]
Manual operation: See "Network" on page 551
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<PhyPt>:
PARameters:C<Cmp> <CircuitModel>, <Capacitance>
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<PhyPt>:
PARameters:C<Cmp>? <CircuitModel>
Specifies the capacitance value C<Cmp> in the different circuit models for single
ended port embedding.
VNA command reference
