R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
919User Manual 1178.5966.02 ─ 20
Usage: Event
Manual operation: See "Measure Fixture wizard" on page 546
[SENSe<Ch>:]CORRection:COLLect:LOAD:SELected <CalGroupFile>,
<Standard>, <TestPort1>[, <SecondPortOrAdapter>]
Reloads a set of previously acquired calibration data for a particular standard from a
file in the cal pool. The loaded data may be combined with new calibration measure-
ment data ([SENSe<Ch>:]CORRection:COLLect[:ACQuire]:SELected) in order
to simplify and speed up the new calibration procedure. The channel settings for loa-
ded and new calibrations (e.g. the number of sweep points) must be identical.
Note:
●
The analyzer performs a consistency check for the loaded data. If the loaded file is
incompatible with the channel settings of channel <Ch>, or if it does not contain
data for the specified standard and port(s), a command error message (–100,
"Command error;...") is generated.
●
For a sliding match, the R&S ZNL/ZNLE can acquire and load measurement data
for up to 20 positions per port. Multiple calls of
[SENSe<Ch>:]CORRection:COLLect:LOAD:SELected <CalGroupFile>,
SLIDe, <TestPort> for the same cal group file and test port, implicitly increases
the position until position 20 has been recorded. Subsequent calls will start over at
position 1, overwriting the previously loaded data.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Parameters:
<CalGroupFile> String parameter to specify the name of the loaded cal group
file.
<Standard> THRough | OPEN | SHORt | OSHort | OSHort1 | OSHort2 |
OSHort3 | MATCh | NET | ATT | REFL | SLIDe | ISOLation |
UTHRough
See [SENSe<Ch>:]CORRection:COLLect[:ACQuire]:
SELected on page 897.
<TestPort1> Test port number. For a transmission standard (through, line,
attenuation, symmetric network) or an adapter used as a
"through" the input and output port numbers must be specified.
For reflection standards, only one port number is required.
Setting parameters:
<SecondPortOrAdapter>For a transmission standard or an adapter used as a "through"
this parameter specifies the second test port.
For reflection measurements with an adapter connected
between port and standard, set it to ON.
Otherwise set it to OFF or simply omit it.
