R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
941User Manual 1178.5966.02 ─ 20
[SENSe<Ch>:]CORRection:STIMulus?
Queries the stimulus values of the active calibration. A calibration must be selected
before the command is executed; see example.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Example:
*RST; :CORR:COLL:METH:DEF 'Test',RSHort,1
Select a one-port normalization at port 1 with a short standard
as calibration type.
CORR:STIM?
Query the stimulus frequencies. The response contains 201 fre-
quency values.
CORR:COLL:SEL SHOR,1
Measure a short standard connected to port 1 and store the
measurement results of this standard.
CORR:COLL:SAVE:SEL
Calculate the system error correction data and apply it to the
active channel.
Usage:
Query only
Manual operation: See "Apply" on page 487
[SENSe<Chn>:]CORRection:SSTate?
Returns the system error correction state label of the active trace in channel <Chn>.
The response is a string variable containing the calibration state label in the trace list
('CAL', 'CAI', 'CAL OFF' ..; see Chapter 9.5.4, "Calibration state labels", on page 262).
Suffix:
<Chn>
.
Channel number used to identify the active trace
Example: See [SENSe<Ch>:]CORRection:DATE?
Usage: Query only
Manual operation: See "Apply" on page 487
[SENSe:]FREQuency...
The [SENSe:]... commands set frequency-related parameters, especially the mea-
surement and display ranges for the different sweep types. The frequency ranges for
the different instrument models are listed below; for more details refer to the data
sheet.
Table 11-18: Frequency ranges of R&S
ZNL analyzers
Frequency settings Start, Stop Center Span
R&S ZNL3 5 kHz to 3.0 GHz >5 kHz to <3.0 GHz 1 Hz to 2.999995 GHz
R&S ZNL4 5 kHz to 4.5 GHz >5 kHz to <4.5 GHz 1 Hz to 4.499995 GHz
R&S ZNL6 5 kHz to 6 GHz >5 kHz to <6 GHz 1 Hz to 5.999995 GHz
VNA command reference
