R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
942User Manual 1178.5966.02 ─ 20
Frequency settings Start, Stop Center Span
R&S ZNL14 5 kHz to 14 GHz >5 kHz to <14 GHz 1 Hz to 13.999995 GHz
R&S ZNL20 5 kHz to 20 GHz >5 kHz to <20 GHz 1 Hz to 19.999995 GHz
Table 11-19: Frequency ranges of R&S ZNLE analyzers
Frequency settings Start, Stop Center Span
R&S ZNLE3 1 MHz to 3.0 GHz >1 MHz to < 3 GHz 1 Hz to 2.999 GHz
R&S ZNLE3 with
R&S ZNLE-B100
100 kHz to 3.0 GHz >100 kHz to < 3 GHz 1 Hz to 2.9999 GHz
R&S ZNLE4 1 MHz to 4.5 GHz >1 MHz to < 4 GHz 1 Hz to 4.499 GHz
R&S ZNLE4 with
R&S ZNLE-B100
100 kHz to 4.5 GHz >100 kHz to < 4 GHz 1 Hz to 4.4999 GHz
R&S ZNL/ZNLE6 1 MHz to 6 GHz >1 MHz to < 6 GHz 1 Hz to 5.999 GHz
R&S ZNL/ZNLE6 with
R&S ZNLE-B100
100 kHz to 6.0 GHz >100 kHz to < 6 GHz 1 Hz to 5.9999 GHz
R&S ZNL/ZNLE6 1 MHz to 14 GHz >1 MHz to < 14 GHz 1 Hz to 13.999 GHz
R&S ZNL/ZNLE6 with
R&S ZNLE-B100
100 kHz to 14 GHz >100 kHz to < 14 GHz 1 Hz to 13.9999 GHz
R&S ZNL/ZNLE6 1 MHz to 18 GHz >1 MHz to < 18 GHz 1 Hz to 17.999 GHz
R&S ZNL/ZNLE6 with
R&S ZNLE-B100
100 kHz to 18 GHz >100 kHz to < 18 GHz 1 Hz to 13.9999 GHz
[SENSe<Ch>:]FREQuency:CENTer................................................................................. 942
[SENSe<Ch>:]FREQuency[:CW]..................................................................................... 943
[SENSe<Ch>:]FREQuency:FIXed....................................................................................943
[SENSe<Ch>:]FREQuency:SBANd..................................................................................943
[SENSe<Ch>:]FREQuency:SEGMent:AXIS...................................................................... 944
[SENSe<Ch>:]FREQuency:SPAN....................................................................................945
[SENSe<Ch>:]FREQuency:STARt................................................................................... 945
[SENSe<Ch>:]FREQuency:STOP....................................................................................945
[SENSe<Ch>:]FREQuency:CENTer <CenterFreq>
Defines the center of the measurement and display range for a frequency sweep
(sweep range). The default center frequency is the center of the analyzer's maximum
frequency range: (f
MIN
+ f
MAX
)/2. The range is listed in table Table 11-18.
Suffix:
<Ch>
.
Channel number
Parameters:
<CenterFreq> Center frequency of the sweep
Increment: 0.1 kHz
Default unit: Hz
VNA command reference
