Command reference

R&S

ZNL/ZNLE

946User Manual 1178.5966.02 ─ 20

Note: If the start frequency entered is greater than the current stop frequency, the stop

frequency is set to the start frequency plus the minimum frequency span

([SENSe<Ch>:]FREQuency:SPAN).

If the stop frequency entered is smaller than the current start frequency, the start fre-

quency is set to the stop frequency minus the minimum frequency span.

[SENSe:]HARMonic...

Implements functions related to harmonic grids for time domain transformation.

[SENSe<Ch>:]HARMonic?..............................................................................................946

[SENSe<Ch>:]HARMonic:AUTO......................................................................................946

[SENSe<Ch>:]HARMonic:RTIMe:DATA............................................................................946

[SENSe<Ch>:]HARMonic:RTIMe:THReshold....................................................................947

[SENSe<Ch>:]HARMonic?

Queries whether the current frequency grid is harmonic.

Suffix:

<Ch>

Channel number

Return values:

<arg0>

Usage: Query only

Manual operation: See "Is the Current Grid Harmonic?" on page 363

[SENSe<Ch>:]HARMonic:AUTO <arg0>

Turns the "Automatic Harmonic Grid" function ON or OFF.

Suffix:

<Ch>

Channel number

Parameters:

<arg0> *RST: ON

Options: R&S ZNL-K2

Manual operation: See "Automatic Harmonic Grid" on page 364

[SENSe<Ch>:]HARMonic:RTIMe:DATA <DUTRiseTime>

Sets/gets the minimum rise time the user wishes to measure on the DUT.

Use [SENSe<Ch>:]HARMonic:RTIMe:THReshold to select the underlying rise time

definition.

The set command automatically activates the "Automatic Harmonic Grid" function, i.e.

it sets [SENSe<Ch>:]HARMonic:AUTO to ON.
