R&S ZVB - Page 1020

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1005
<prop_gain>
Proportional gain setting
Range [def. unit]
0 dB to 100 dB [dB]. UP and DOWN increment the proportional gain in 0.001
dB steps.
*RST value
0.4 dB
SCPI, Command
Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:ALC:PIParameter
SOURce<Ch>:POWer<Pt>:ALC:PIParameter:ITIMe <int_time>
Defines the integration time of the PI controller at source port <Pt> in channel <Ch> (Control Loop
Parameters > Ki in ALC Config dialog). This setting takes effect when manual setting of the controller
parameters is enabled (SOURce<Ch>:POWer<Pt>:ALC:PIParameter MANual).
<Ch>
Channel number
<Pt>
Port number
<prop_gain>
Integration time setting
Range [def. unit]
10 ns to 100 s [s]. UP and DOWN increment the integration time in 10 ns
steps.
*RST value
500 ns
SCPI, Command
Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:ALC:PIParameter
SOURce<Ch>:POWer<Pt>:ALC:POFFset <Boolean>
Causes the analyzer to use the ALC of the previous measurement as an ALC start offset value for port
<Pt> in channel <Ch> (Start Value > Last Meas in ALC Config dialog).
<Ch>
Channel number
<Pt>
Port number
<Boolean>
ON | OFF -Use ALC Offset... on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:ALC:AUBW
SOURce<Ch>:POWer<Pt>:ALC:RANGe <cont_range>
Defines the maximum change of the source signal level due to the ALC (Control Range in ALC Config
dialog) for port <Pt> in channel <Ch>.
