Parameters
FACTory - Use factory data (only supported by R&S ZCxxx converter models)
USER - Use linearization data collected with the leveling tool. The path to the
user data folder is specified using SENS:CONV:PATH.
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command
Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:PATH
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:ELECtronic:LIMit <threshold>
Specifies the converter output power threshold for a converter with electronic attenuators at port <Pt>.
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
<threshold>
Converter output power below which the waveguide attenuator is used
Range [def. unit]
–300 dBm to +200 dBm [dBm], the increment (UP | DOWN) is 0.1 dB
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:ELECtronic:MATTenuation
<attenuation>
Specifies the maximum attenuation for a converter with electronic attenuators at port <Pt>.
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
<attenuation>
Maximum attenuation due to the waveguide attenuator
Range [def. unit]
0 dB to INF [dB], the increment (UP | DOWN) is 0.1 dB
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:ELECtronic:REDuction
<percentage>
Specifies the percentage of power reduction for a converter with electronic attenuators at port <Pt>.
Since FW version 3.40 this is a global setting.
