R&S ZVB - Page 1026

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1011
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
<percentage>
Percentage of power reduction due to the waveguide attenuator
Range [def. unit]
1 % to 100 % [%], the increment (UP | DOWN) is 1 %
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:MECHanical:ATTenuation
<attenuation>
Specifies the attenuation factor for a converter with mechanical adjustment screw at port <Pt>.
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
<attenuation>
Attenuation due to the adjustment screw
Range [def. unit]
0 dB to INF [dB], the increment (UP | DOWN) is 0.1 dB
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:OFFSet <offset>
Specifies the offset factor for the linear power transfer approximation (Offset value in Linear Approximation
dialog).
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
Parameters
Offset in the linear power transfer model
Range [def. unit]
–300 dB to +300 dB [dB], the increment (UP | DOWN) is 1 dB
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:PATH '<directory>'
This command specifies the user data directory for the RF In Power (and Electronic Attenuator) with Data
