source port and the target power of +35 dBm.
SOURce<Ch>:POWer<Pt>:CORRection:GENerator<Gen>[:STATe] <Boolean>
Enables or disables the source power calibration for channel <Ch> and for an external generator number
<Gen>. The command is disabled unless a source power calibration for the external generator has been
performed (SOURce<Ch>:POWer<Pt>:CORRection[:ACQuire] GENerator, <source_pt>). To
enable or disable a source power calibration for an analyzer port use
SOURce<Ch>:POWer<Pt>:CORRection[:STATe].
<Ch>
Calibrated channel number
<Pt>
Calibrated port number. This suffix is ignored; the generator is selected via
<Gen>.
<Gen>
Generator number
<Boolean>
Enables (ON) or disables (OFF) the source power calibration for an external
generator number <Gen>.
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CORRection[:ACQuire].
SOURce<Ch>:POWer<Pt>:CORRection:HARMonic[:ACQuire]
Starts the source calibration (1
st
power calibration step for harmonic measurements), stores and applies
the calibration data. The external power meter used is selected via
SOURce<Ch>:POWer<Pt>:CORRection:PMETer:ID.
<Ch>
Calibrated channel number
<pt>
Port number This suffix is ignored; the analyzer calibrates the port that is selected as
a source port for the harmonic measurement
([SENSe<Ch>:]FREQuency:CONVersion:HARMonic:SPORt).
SCPI,
Command
Types
Device-specific, no query
Example:
*RST; FREQ:STAR 0.5E+9; STOP 1E+9
Reset the analyzer (activating a frequency sweep) and set the sweep range between
1 GHz and 1.1 GHz.
FREQ:CONV:HARM:ORD 4; SPOR 1; RPOR 2
Configure a 4
th
harmonic measurement with source port 1 and receive port 2. The
measurement is still not enabled.
FREQ:CONV HARM
Enable the configured harmonic measurement.
SOUR:POW:CORR:PMET:ID 1
