'<driver>'
Generator type (string parameter). The generator type is identical with the name
of the generator driver file (*.gen) stored in the resources\extdev subdirectory of
the analyzer's program directory. Type the driver file name as shown in the Add
External Generator dialog, i.e. without the file extension ".gen" (example: use
'sme02', if the corresponding driver file name is sme02.gen).
Alternative: The '<driver>' string may also contain the generator driver file name
with its complete path, e.g. 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\resources\extdev\sme02.gen'.
'<interface>'
Interface type (string parameter): 'GPIB0', 'VXI-11',...
'<address>'
Interface address (string parameter), depending on the interface type.
<fast_sweep>
Optional Boolean parameter, enables or disables the list mode (triggered mode).
<10_MHz_Ref>
Optional Boolean parameter, sets the generator to internal (OFF) or external (ON)
reference frequency.
*RST values
*RST has no effect on the configured generators.
SCPI,
Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
SYST:COMM:RDEV:GEN1:DEF?
Query the generator configuration. The response 'Ext. Gen.
1','SME02','GPIB0','21',OFF, OFF indicates that the fast sweep mode is
disabled and that the analyzer is set to internal reference frequency.
SYST:COMM:RDEV:GEN1:DEL
Clear the generator configuration table.
SYST:COMM:RDEV:GEN1:DEF?
Query the generator configuration. The analyzer returns an error message
because the generator no. 1 is no longer configured.
SYSTem:COMMunicate:RDEVice:GENerator<gen_no>:DELete
Clears the configuration table for external generators.
<gen_no>
Number of the configured generator. This number is ignored, the command clears
all entries in the configuration table.
SCPI,
Command
Types
Device-specific, no query
Example:
See SYSTem:COMMunicate:RDEVice:GENerator<gen_no>:DEFine
SYSTem:COMMunicate:RDEVice:PMETer<pmeter_no>:AZERo
Starts auto zeroing of the external power meter.
